Frequency Converter WACKER NEUSON FUE 10

“Description
Lightweight, robust and high capacity: The FUE range The outstanding feature of the FUE range of frequency converters is its lightweight, compact design. Thanks to their aluminium construction they are very easy to handle. Their high-quality electronics and active cooling system ensure maximum performance even in continuous peration. The intelligent voltage and power management is particularly practical. It compensates for fluctuations of mains input voltage, wrongly dimensioned extensions or appliances with greatly varying use of power.
– The FI protective switch is sensitive to pulsating currents.Therefore the devices can be used practically anywhere.
– Maximum safety: Galvanic isolation with isolating transformer.
– Maintenance-free.
– Intelligent voltage and power management.” “Spesifikasi Produk
Model Number FUE 10
Unit 1unit
Dimensions (LxWxH) (mm) 500x500x550
Frequency Converter Mitsubishi
Input Voltage (V) 400 (3phase)
Output voltage (V) 42 (3phase)
Input Frequency (Hz) 50-60
Frequency Adjustment Range (Hz) 0-200
Input Current (A) 24.5
Output Current (A) 145
Input Performance (kVa) 17
Output Performance (kVa) 10.5
Protection Class IP 54
Power Cable (m) 3
Berat (Kg) 87.0”
